Wall mount eye wash – all stainless steel

Wall mounted eye wash 7778B AXION - all stainless steel components - AXION face+eye wash head

Request a Quote Spec Sheet Download

Wall mount eye wash – all stainless steel

The Haws® eye wash model 7778B AXION is the optimal solution for industrial applications where highest corrosion resistance is required. It complies to the standards EN 15154-2 and ANSI Z358.1. All components are made of stainless steel and makes this permanently installed eye wash extremely corrosion resistant and very rugged. The patented AXION® shower head delivers reliable a compliant water jet for rinsing simultaneously eyes and face. The unique, centered AXION water jet eliminates the main issues of other eye wash systems to provide proper first aid. Model 7778B AXION also includes a stainless steel wall bracket, yellow plastic pop-off dust cover for eye wash head and eye wash safety sign.

Technical information

  • Water flow: 14 liters/minute
  • Application: indoor/outdoor
  • Dimensions (H x W x D): 300 x 381 x 470 mm
  • Water inlet: G 1/2"
  • Water outlet: G 1"

Characteristics Eye wash 7778B AXION

  • Pre-built and fully water/pressure tested
  • Increased safety due to AXION face+eyewash head and integral flow control
  • Corrosion resistant 28 cm type 304 stainless steel bowl
  • Reliable stainless steel type 304 ball valve equipped with stainless steel ball and stem
  • Stainless steel type 304 in-line mesh strainer to prevent debris
  • Robust stainless steel type 304 wall bracket
  • Including universal safety sign
  • Wide range of options for adapting to on-site requirements
