7433FP AXION

Wall mount eye wash – freeze-protected – stainless steel

Model 7433FP AXION, wall-mounted, freeze protected eyewash

Request a Quote

Wall mount eye wash – freeze-protected – stainless steel

Haws emergency eyewash systems, like the freeze protected 7433FP AXION, use AXION head that activate with the push of a stainless steel flag. Head comes equipped with pop-off dust cover, so when debris is present, the irrigation process stays protected. Space efficient design and integral wall bracket allow the 7433FP AXION to be mounted in a number of easily accessible locations.

  • A great addition to multiple unsafe environments where the eyes may be exposed to corrosive materials
  • Easily detected and maintained, emergency equipment is equipped with safety sign and test card to record weekly testing
  • Reducing installation time, eyewash and valve assembly is pre-built and fully water/pressure tested
  • Fully functional in freezing environments when installed properly
  • EN 15154 compliant
Certified by CSA to meet the ANSI Z358.1 Standard for Emergency Eyewash and Shower Equipment

Certifications
  • EN 15154-2:2006
  • ANSI Z358.1-2014 (R2020)

Specifications

Model 7433FP AXION freeze protected wall-mounted eyewash shall include a stainless steel 11" (27.9 cm) round bowl, stainless steel eyewash yoke assembly with AXION head with integral flow control and dust cover, self-draining valve, and brass stay-open ball valve equipped with stainless steel ball and stem, and stem extension. Unit to be used with a maximum wall thickness of 15" (38.1 cm) and shall include chromate protective cast-aluminum wall bracket, universal sign, 1/2" NPT inlet, and 1-1/4" NPT outlet.
