7656WCC AXION

Barrier-free flush-mounted eyewash with drain pan

Model 7655WCC AXION โ€“ barrier-free โ€“ for flush mounting โ€“ fold-down eyewash with drain pan โ€“ AXION eyewash head โ€“ stainless steel housing

Request a Quote

Barrier-free flush-mounted eyewash with drain pan

The Hawsยฎ 7656WCC AXION is a barrier-free eye wash for space-saving flush mounting. It was specially developed for laboratories, corridors, and narrow passagewaysโ€”anywhere where space is limited but standard-compliant first aid must still be guaranteed.

The 7656WCC AXION has an integrated stainless steel drain pan with a panic bar. The eyewash is automatically activated when the drain pan is folded down. The patented AXIONยฎ showerhead produces a gentle, even stream of water for effective rinsing of the eyes and face. Its barrier-free operation and robust construction make this model ideal for safety-critical indoor areas.

The eyewash meets the requirements of EN 15154-2 and ANSI Z358.1.

Technical information Barrier-free flush-mounted eye wash with drain pan 7656WCC AXION

  • Flow rate: 14 liter/minute
  • Flow pressure: min. 2.1 bar, max. 6 bar
  • Static pressure: max. 8 bar
  • Water connection: NPT 1"
  • Water drain: NPT 2"

Product highlights 7656WCC AXION

  • Space-saving flush-mounted installation โ€“ ideal for laboratories and corridors
  • Stainless steel drain pan with integrated panic bar
  • AXIONยฎ technology for standard-compliant decontamination
  • Robust stainless steel design for long-lasting safety
  • Barrier-free operation with automatic activation
  • Complies with EN 15154-2 and ANSI Z358.1

Ordering information 7656WCC AXION

  • Item number: 10004563
  • Country of origin: USA

Certifications
  • EN 15154-2:2006
  • ANSI Z358.1-2014 (R2020)
